OTTAWA

TERMINAL TRACTORS

• Increased visibility with a more ergonomic cab
• Taller and wider door for easier entry and exit
• Larger, roomer and more comfortable cab environment with everything in easy reach
• Open C channel chassis design provides more strength, better protection and less maintenance
• Suspended control pedals for better operator feel and control
• Faster and stronger fifth wheel lifting, with spherical bearings both bottom and top
• Tapered 3-Leaf Springs help provide a smoother ride. No front spring lubrication required
• Easier serviceability. Ground-level service points and systems access available through cab panels

Need Help? CLICK FOR SALES

4×2 Off-Road

Tried and true…the standard of the industry for general purpose off-road trailer spotting.

• 116” Wheelbase 4×2 DOT/EPA Certifie
• Cummins ISB6.7 200 hp 2013 Clean Idle, Certified @ 2,300 rpm, 520 lb/ft torque @ 1,600 rpm, with OBD
• Allison 3,000RDS 6-Speed Automatic Transmission
• Meritor FF-961 Front & RS-24-160 Rear Axles
• Holland FW-35-70,000-lb. Plate Rating Fifth Wheel
• 5” Hydraulic Cylinders 17” Lift, 60,000-lb. Rating
• Max Speed 33 mph w/o ABS, 45 mph w/ ABS
• GCWR 81,000 lbs.

Need Help? CLICK FOR SALES

4×2 DOT/EPA

On-road capability offers expands usage for short-shuttling and other hauling between work sites.

• 116” Wheelbase 4×2 DOT/EPA Certified
• Cummins ISB6.7 200hp 2013 Clean Idle, Certified @ 2,300 rpm, 520 lb/ft torque @ 1,600 rpm, with OBD
• Allison 3000RDS 6-Speed Automatic Transmission
• Meritor FF-961 Front and RS-24-160 Rear Axles
• Holland FW-35-70,000-lb. Plate Rating Fifth Wheel
• 5” Hydraulic Cylinders 17” Lift, 60,000-lb. Rating
• Max Speed 31-33 mph w/o ABS, 45 mph with ABS
• GCWR 81,000 lbs.

Need Help? CLICK FOR SALES

6x4 DOT/EPA

Two rear axles and 4-wheel drive provide increased flexibility, in rougher and inclined terrain.

• 146” Wheelbase 6×4 DOT/EPA Certified
• Cummins ISB6.7 200 hp 2013 Clean Idle Certified @ 2,300 rpm, 520 lb/ft torque @ 1,600 rpm
• Allison 3000RDS 6-Speed Automatic Transmission
• Meritor FF961 Front and RT-40-145 Rear Axles
• Holland FW-35–70,000-lb. Plate Rating Fifth Wheel
• 5” Hydraulic Cylinders 17” Lift, 60,000-lb. Rating
• Max Speed 31-33 mph w/o ABS, 45 mph with ABS
• GCWR 81,000 lbs
